Spacer for cover
Type AH 35 WS A2
|Item no. 6065477
|EAN 4012196055913
Item no. / Type
6065477 / AH 35 WS A2
Smallest selling unit: 8 piece
8piece
piece
Description
Spacer for stand-off mounting of covers on wide span cable trays and wide span cable ladders. Space height 35 mm, stainless steel 1.4301.
Technical data
Dimensions
| Width | 30 mm |
|---|---|
| Height | 35 mm |
Technical data
| Rustproof steel, pickled | no |
|---|---|
| Suitable for mesh cable tray | no |
| Suitable for cable ladder | yes |
| Suitable for cable tray | yes |
| ROHS-conformant | yes |
| Dimension | 35x30 |
| Surface | Bright, treated |
| Material | Stainless steel 1.4301 |
| Colour | stainless steel |
Environmental Data
1,2119 kg CO2e / 1 PieceCO2 Footprint (GWP) Cradle-to-Gate
| CO2 Footprint (GWP) Cradle-to-Gate | 1,2119 kg CO2e / 1 Piece |
|---|---|
| CO₂ Footprint (GWP) | 1,2119 kg CO₂e |
| Determination date of CO2 value | 2025-05-14T00:00:00.000+0200 |
| Declared Unit | Units |
| Declared Unit Quantity | 1 |
Downloads
0 selected
Data sheet (1)
Catalogues & Flyers (5)
Declarations (4)
Instructions and Aid (2)
Product images (2)
3D data downloads (1)
Tender specifications (1)
