Fastening pin for mounting plates
Type T-S MST | Item no. 2007831 | EAN 4012195615910
Item no. / Type
2007831 / T-S MST
Smallest selling unit: 100 piece
100piece
Description
Metal fastening pin for fastening the T series onto mounting plates or other thin-walled supporting structures. Mounted by simply pressing the bolt into the fastening holes in the T series. Easy removal with a screw thread.
Technical data
Dimensions
| Length | 11,5 mm |
|---|---|
| Dimension L | 11,5 mm |
| Dimension D | 3,5 mm |
Technical data
| Thread metric | 3 |
|---|---|
| Thread | M3 |
| Screw system | Phillips PH with screw slot |
| Dimension | Ø3,5x10 |
| Surface | Electrogalvanized |
| Material | Steel |
| CO2 Footprint (GWP) Cradle-to-Gate | 0,0024 kg CO₂e / 1 Piece |
Downloads
0 selected
Data sheet (1)
Catalogues & Flyers (6)
Declarations (2)
Product images (2)
Tender specifications (2)
Variants
Type
Item no.
T-S MST
2007831
T-S MST
Item no.
2007831
