Connection clamp AB EX ISG, straight
Type AB EX ISG S M24
|Item no. 5240374
|EAN 4012196524297
Item no. / Type
5240374 / AB EX ISG S M24
Version for
For M24 bolt
Smallest selling unit: 2 piece
2piece
piece
Description
Connection clamp for mounting the OBO Ex spark gap, type EX ISG, on insulating flanges and insulating pieces.
Technical data
Technical data
| Version for | For M24 bolt |
|---|---|
| Drill hole diameter, min. | 26 mm |
| Dimension | 120x45x40 |
| Surface | Hot-dip galvanised |
| Material | Steel |
| Accessories | yes |
| Spare part | no |
CO2 footprint (Product Carbon Footprint)
| CO2 Footprint (GWP) Cradle-to-Gate | 0,4494 kg CO2e / 1 Piece |
|---|
